EMI Filter All Series Description

1. CLASSIFICATION OF PRODUCT

Model Number:





COMPANY NAME

SERIES

CURRENT RATE

TERMINALS

TWO STAGE

    Terminal Style Description

    • A1 / T1 : .250" Fasten Terminal
    • A3 / T3 : Solder Lug Terminal
    • T4 : m-4 Screw Terminal
    • T5 : Chassis Mount Solder lug Terminal
    • T6 : PCB Type Terminal
    • T7 : m-5 High Current Screw Terminal
    • T8 : PCB Type Terminal
    • T9 : PCB Mounting Terminal
    • T10 : m-10 High current screw terminal
    • T12 : m-12 High current screw terminal
    • P : PCB Type terminal






A
-
1A,3A,6A,10A
-
T1,T3,P




B
-
1A,3A,6A,10A
-
T1,T3,A1,A3




C
-
5A,10A,15A,20A
-
T1
-
L2


D
-
5A,10A,15A,20A
-
T4
-
L2


E
-
5A,10A,15A,20A,30A
-
T1, T4
-
L2


F
-
1A,3A,6A,10A
-
T6


Y

G
-
1A,3A,6A,10A
-
T5


-
H
-
10A,15A,20A,30A
-
T4



I
-
40A,50A,60A
-
T7




J
-
30A,40A,50A,60A
-
T7




K
-
1A,3A,6A,10A
-
T1




L
-
1A,3A,6A,10A
-
T1




M
-
15A,16A
-
T1




N
-
2A
-
T9
-
L2


O
-
1A,3A,6A,10A
-
T1,T3,A1,A3




P
-
60A,80A,100A,150A
-
T8,T10,T12




Q
-
1A,2A,4A,6A
-
A1



2. PRODUCT DESCRIPTION

YA Series



 YA T1,T3 Series (1-10 Amp) Screw mount, Compact size with IEC connector, Low cost, 250 terminals(T1), Solder lug terminals(T3), 90 Degrees input/output terminals (All YA Series)
YAC-T1,T3 Series (1-10 Amp) Highest performance compact filter with IEC connectors, additionally ground choke, 250 terminals (T1), Solder lug terminals (T3)
YA-P Series (1-10 Amp) General purpose, Low cost, Output PCB type terminals
YAC-P Series (1-10 Amp) Highest performance low cost compact filter, additionally ground choke, Output PCB type terminals
YB Series

 YB-A1, A3 Series (1-10 Amp) Whole surround case with IEC connector, Low cost, 250 terminals(A1), Solder lug terminals(A3), 180 Degrees input/output terminals (All YB Series)
(1-10 Amp) General purpose filter with IEC Connector, Low cost, 250 terminals(T1), Solder lug terminals(T3)
(1-10 Amp) Highest performance compact filter with IEC connector, Ground choke included , 250 terminals(T1), Solder terminals(T3)
YC Series
(5-20 Amp) Superior performance provide needed noise suppression of line to line and line to ground noise, 250 fasten terminals
(1-10 Amp) Two stage filters, Highest performance    controlling line to line and line to ground noise, 250 fasten terminals
YD Series
(5-20 Amp) Superior performance for line to line and line to ground noise, Screw input/output terminals
(1-10 Amp) Two stage filters, Highest performance  controlling line to line and line to ground noise, Screw input/output terminals
YE Series
(5-30 Amp) Up to 30 Amp general purpose High performance line to line noise rejection, 250 terminals (T1), M-4 Screw terminals(T4)
(5-20 Amp) Two-Stage T section power line filter,  Premium performance at moderate cost, 250 Terminals (T1), M-4 Screw terminals(T4)

YF Series

(1-10 Amp) Standard design allow PC board mountable terminals, Low cost, Designed to bring most digital equipment

(1-10 Amp) Compact size designed, 1mm printed circuit terminals, Hi resistance performance, low cost.
YG Series
(1-10 Amp) Cost effective to chassis mountable component for applications requiring more line to line protection, available up to 10 amps
YH Series
(10-30 Amp) Three Phase External Power Line Filter, M-4 Screw input/output Terminals, High Reliability for Industrial Equipment
YI Series
(40-60 Amp) Three phase filtering work well in both forward and reverse directions for industrial applications, M-5 Hi current screw terminals
YJ Series
(30-60 Amp) Single phase 250/500vac, both common mode and normal mode good noise suppression from 50 KHz to 30 MHz, High reliability designed for industrial applications
YK Series
(1-10 Amp) General purpose in a small size at low cost, designed to meet a wide variety of electronic and electrical applications, 250 terminals.
YL Series
 (1-10 Amp) Power entry modules combine the IEC power socket and single fuse holder, in the smallest possible panel space. 250 terminals.
YM Series
(15-16 Amp) General Purpose for High Impedance load 15, 16A models, IEC connector and 250 terminals.
YN Series
 (2 Amp) PC Board mountable terminals with Flange style case, 2 stage filter offers a high performance and high impedance attenuation.
YO Series
 (1-10 Amp) Snap-In panel mounting type (top & bottom side), 250 terminals(A1), solder terminals(A3)
(1-10 Amp) Snap-In panel mounting type (left & right side), 250 terminals(A1), solder terminals(A3)
YP Series
 (60-150 Amp) Good noise attenuation in both forward and reverse directions for common mode and normal mode. High current and reliability designed for industrial equipment usage with 3 phases, 500vac, YP150T12 provided 4 wire (plus neutral)
YQ Series
 (1-6 Amp) Multi function power entry connector with dual fuse holder, DPST on/off switch, vertical design for flange panel mounting, 250 terminals

3. SAFETY APPROVALS

COUNTRY AND TEST AUTHORITY
APPROVAL MARK
TEST STANDARD
HIGH VOLTAGE TEST
R-INSULATION
KV (1Min)
HZ
L-L, L-G
Ohm 10
Vz (1Min)

GERMANY
VDE
VDE
SECC 32 400
32 401
4.3 X Vn
1.5
0
50
L--L
L--G
1500
200
100
100
CANADA
CSA
CSA
C22,2
(2Vn+0.5)1.4/4
>=1.414
2 Vn + 1
0
60
L--L
L--G
6000/N
N:NUMBER
Cond. 11
100
U.S.A.
UL
UL 1283
2.121
1.250
0
60
L--L
L--G
2
250
SEMKO DEMKO
FIMKO NEMKO
4432901
4.3 X Vn
2 XVn + 1.5
0
50
L--L
L--G
6000
100
